Ecco 9013A Z1000 Hide Away Amber LED Head PN: 9013A
VisionAlert [ECCO]

Ecco 9013A Z1000 Hide Away Amber LED Head PN: 9013A

9013A

The Z1000 utilizes the latest LED technology to deliver high-intensity, pure colored LED light blasts where you need them most.

excl. VAT £96.00
(incl. VAT £115.20)

Z1000 LED Undercover Warning Signal

No more replacing strobe tubes year after year! The Hide-A-LED Z1000 is the next-generation of undercover warning signal.

The Z1000 utilizes the latest LED technology to deliver high-intensity, pure colored LED light blasts where you need them most. Available colors- Amber, Blue,

The Hide-A-LED Z1000 features a state-of-the-art, in-line molded power module that offers maintenance-free operation.

The Z1000 has an Intergrated Heatsink which must be used to maintain a safe operating temperature. The Integrated Heatsink can be bent into any shape needed to fit the space available for the application.

By combining the power module, cable and LED head, the Hide-A-LED Z1000 warning signal eliminates common electrical issues caused by exposure to moisture and reduces installation time to a minimum. Fast installations and trouble-free operation offers fleet managers the additional benefit of less vehicle down-time.

  • 6 Next-Generation LEDs.
  • UV Stabilized Polycarbonate Lens.
  • Nickel Plated Housing.
  • Low Profile Mounting Flange.
  • High Current LED Driver.
  • Self-Contained Power Module.
  • In-Line Power Module.
  • 9 foot, pre-wired cable.
  • Mounts into 1" hole.
  • 5 Year Warranty

Specifications

SOLID:
INPUT VOLTAGE: 10 TO 30 VOLTS DC.
INPUT CURRENT: 1.25A @ 12.8V, 0.6A @ 25.6V
LIGHT OUTPUT:
AMBER: 358+ LUMENS
BLUE: 240+ LUMENS
GREEN: 312+ LUMENS
RED: 358+ LUMENS
WHITE, PURPLE: 1,100+ LUMENS


SPLIT:
INPUT VOLTAGE: 10 TO 30 VOLTS DC.
INPUT CURRENT: 0.5A @ 12.8V, 0.3A @ 25.6V
LIGHT OUTPUT: (FOR EACH 2LED SEGMENT)
AMBER: 180+ LUMENS
BLUE: 120+ LUMENS
GREEN: 104+ LUMENS
RED: 180+ LUMENS
WHITE: 550+ LUMENS


CABLE LENGTH   9 FT.
LED ELEMENTS   6
FLASH PATTERNS   16 (8 Standard, 8 optional cycle)
MAX NUMBER OF
SYNCRONIZED HEADS  64
WARRANTY PERIOD   5 YEARS

Please use caution when handling Hide-A-LED after use - heatsink will become hot after running for an extended period. The heat will NOT melt any of the plastic parts of the lens assembly.

Dimensions

Height: 1.3"

Diameter: .96"
